Small Air Forces and #HighIntensityWar: Multinational Cooperation as an Opportunity to Build and Strengthen their Capabilities

Small Air Forces and #HighIntensityWar: Multinational Cooperation as an Opportunity to Build and Strengthen their Capabilities

By Maria E. Burczynska

The introduction to the recent #highintensitywar series run by From Balloons to Drones and The Central Blue suggested that the character of military conflict is changing due to the increased possibility of high-intensity war, which, in turn, will present significant challenges to Western militaries. While the series introduction suggested that post-Cold War conflicts presented few challenges for air forces seeking to maintain control of the air the increasing likelihood of a high-intensity war may well change that scenario. In such a case, not only will the ability to achieve air dominance be challenging but also, if that is not achieved then the ability to perform the full spectrum of air power roles and using all capabilities available may be restricted too. Such a situation may prove especially difficult for small air forces which often lack specific capabilities in the first place.

This article focuses predominantly on small European air forces with Poland and Sweden as case studies. It discusses the situation in which these two air forces find themselves after the end of the Cold War and the changes they have undergone. In doing so, this article also briefly introduces some of the general trends and challenges that took place during the post-Cold War years in Europe such as decreasing defence budgets and the downsizing of armed forces. The article identifies principal areas where small European air forces suffer from capability shortcomings and then moves on to discuss the role of multinational cooperation as a means to make up for these gaps.

What is a Small Air Force?

When speaking of a small air force, one could think of it looking at its actual size, its number of the aircraft and its number of personnel. However, this article defines a small air force according to its capabilities. This follows the definition provided by Sanu Kainikara who recognised four categories of air forces; the US Air Force, large air forces, small air forces and niche air forces. These differ from each other regarding the scope of their capabilities, their ability to pursue operations independently as well as the presence of an indigenous industry supporting the air force’s needs at the national level.[1] According to this classification, small air forces can perform the four fundamental roles of air power; control of the air, intelligence, surveillance and reconnaissance (ISR), attack and air mobility. On the other hand, small air forces do not have the resources necessary to undertake such roles to a considerable extent and over a prolonged period. Therefore, small air forces would not be able to conduct independent large air operations. However, they are often the desired ally that can efficiently work within a coalition.

Both the Polish and Swedish Air Forces (AF) comfortably fit into the category of a small air force. They have necessary resources to perform the full spectrum of capabilities within the already mentioned air power roles. However, their resources are insufficient, sometimes falling to single numbers of an aircraft of specific types. That makes them unable to perform independent large-scale military operations. Finally, both countries have some industrial capacity to support national air power capabilities, such as PZL Mielec and PZL Świdnik, now part of respectively Sikorsky Aircraft Corporation and Leonardo-Finmeccanica’s Helicopter Division in Poland, or Saab in Sweden.

European Air Power after 1991

In the post-Cold War years European air forces and militaries, in general, underwent certain transformations. Primarily, military expenditure by European states has dropped noticeably. In Poland, defence expenditure has decreased from 2.6% of the GDP in 1990 to 2.0% in 2016 while in Sweden it has dropped from 2.6% to 1.0% in the same period.[2] In line with decreasing defence budgets was the gradual downsizing of air forces and the armed forces in general. For example, in Poland, the number of active personnel has dropped from 86,200 men in 1990 to 16,600 in 2015.[3] At the same time, the number of officers serving in the Swedish AF fell from 8,000 to 3,300.[4] Moreover, it was not only manpower that dropped in numbers but also available equipment. The Polish AF reduced from 800 aircraft in 1990 to 300 in 1998 with the target of 100 to be reached in 2002.[5] A similar process also took place in the Swedish AF, but, in this case, it was initiated as early as the 1960s when the number of combat aircraft started to drop from 800 and reached 400 in the 1990s.[6]

The above situation led to specific organisational and structural changes within both the Polish and Swedish AFs. In case of the Polish AF, these transformations started at the very top when the Air Force (Wojska Lotnicze) and the Country Air Defence Force (Wojska Obrony Powietrznej Kraju) merged to form the Air Force and the Counter-Air Defence Forces (Wojska Lotnicze i Obrony Powietrznej). In 2004, the latter formation was finally re-named as the Polish Air Force (Siły Powietrzne). Also, the building blocks of the Polish AF was changed by replacing two of its existing squadrons with regiments.[7] Similar re-organisation took place within the Swedish AF when out of its 12 Wings, and the main air bases, only four remained operational while the other eight were closed.[8]

The transformation of the two air forces also involved modernisation of their already reduced fleets. In Sweden, that process focused on three areas. First, the Swedish AF replaced its AJ/JA-37 Viggen aircraft with JAS-39 Gripen. Second, it introduced more advanced types of munitions and then finally it has sought to upgrade its command, control, communications, and intelligence system.[9] For Poland, the air force modernisation was challenging because the overwhelming majority of the country’s aircraft was built either in the Soviet Union or under licence from them. In the post-Cold War years, these aircraft delivered little modern combat capability. As such, in the process of modernisation, the Polish AF replaced its MiG-21 and MiG-23 fighters with 22 MiG-29s bought from Germany in 2003 and 48 F-16s delivered in years 2006–2008 from the US. They also acquired 17 CASA C-295M transportation aircraft.[10] Finally, on the 1 January 2016, Poland opened the twelfth unmanned aerial vehicle (UAV) base that was the first of its kind in the country.

105 Polish Air Force MiG-29A Fulcrum ILA Berlin 2016
A Polish Air Force Mikoyan-Gurevich MiG-29A Fulcrum at the ILA Berlin Air Show 2016. (Source: Wikimedia)

Limitations of European Air Power

Despite all the organisational and structural transformations, and fleet modernisation that has taken place over the last 30 years, the Polish and Swedish AFs remain small air forces and, as such, somewhat limited in their capabilities. Principally, their fleets are relatively small; the Polish AF possesses 283 aircraft in total while the Swedish AF numbers 231 airframes including the inventory of the Armed Forces Helicopter Wing.[11] However, the Polish and Swedish AFs are also limited in areas that are representative of the significant shortcomings of European air power in general, namely air transport (AT), ISR and air-to-air refuelling (AAR). Significant gaps in these three areas were identified as early as the conflicts in Bosnia and Kosovo in the 1990s. However, these capability gaps have become even more evident after the involvement of European air forces in operations over Libya in 2011. Operations over Libya revealed not only the low capacity of European air forces in the areas of AT, ISR, and AAR resources but also their heavy reliance on the US for those capabilities.[12]

Both Poland and Sweden continue to experience significant shortcomings in these three areas. For example, the Polish AF has only 45 transport aircraft while for Sweden that number drops to barely eight.[13] The differences are even more significant when it comes to ISR and AAR. In case of AAR, the Swedish AF has one tanker aircraft.[14] Poland, on the other hand, does not possess any aircraft of that type. However, in 2014, together with Norway and the Netherlands, Poland decided to acquire a fleet of Airbus A330 multi-role tanker transports.[15] The situation is similar in the realm of ISR. Sweden has five ISR aircraft while the Polish have none.[16]

Examples of Multinational Cooperation Initiatives

Multinational cooperation is one way to make up for such shortcomings in small air forces where resources are limited. It is also the cost-effective option. This cooperation takes different forms, from pooling and sharing resources to training programmes but they are always collective initiatives. As such, these initiatives require participating states to be willing to share the costs of running the project in areas such as the acquisition and maintenance of platforms. As a result, multinational cooperation can significantly reduce the financial burden that would be placed on a small air force if it were to develop such capabilities from scratch. Such pooling and sharing of capabilities also present a viable interim solution in the case where a country is already working towards developing a particular capability that has not yet become fully operational. An example of such an initiative is Poland’s involvement in the Alliance Ground Surveillance (AGS) programme whereby 15 NATO members are acquiring a system consisting of five RQ-4 Global Hawk UAVs and advanced radar systems, which altogether will allow for providing persistent surveillance from high-altitudes.[17] This initiative presented a viable interim solution for Poland which does not possess any air surveillance capability. While Poland is currently developing a UAV fleet which could provide that capability, until it becomes fully operational, AGS can fill that gap. Poland had been a member of the AGS programme until 1 April 2009 when the country withdrew due to financial reasons. Poland later re-joined the programme in April 2014.[18] Another way to make up for the lack of national ISR capability is participation in the NATO Airborne Early Warning (NAEW) system. The initiative started in 1982 and, as such, is one of the oldest and the most successful cooperative initiatives in NATO and Europe. Poland joined NAEW in 2006.[19]

An exciting initiative addressing both the lack of AT and AAR capability, but pursued outside of NATO and EU frameworks, is the Air Transport, Air-to-Air Refuelling, and other Exchange of Services (ATARES) programme developed by the Movement Coordination Centre Europe (MCCE). This project promotes the exchange of services – AAR for AT calculated using Equivalent Flying Hour (EFH).[20] For example, Poland does not have an AAR capability. Therefore, Poland uses ATARES to give aircrews an opportunity to train on those particular platforms and, in return, offers AT capabilities.[21] Interestingly that capability does not have to be provided to that particular country from which AAR was used in the first place. The agreed number of EFH need only to be returned to the initiative and therefore may be used by any one of its members. Sweden offers its AAR services within ATARES even though there is only one tanker in the Swedish AF. For example, in 2017, MCCE provided refuelling support during the Arctic Challenge Exercise, and that support involved the Swedish aircraft.[22]

Other examples of multinational initiatives addressing limitations in national AT capabilities are the Strategic Airlift Interim Solution (SALIS), and the Strategic Airlift Capability (SAC) started in 2005 and 2008 respectively. These are pooling and sharing projects whereby participating states maintain a certain number of aircraft and use these according to their needs. For example, SALIS was created to transport heavy cargo and Poland used the programme to transport helicopters and armoured vehicles to Afghanistan.[23] SAC was designed to support the participating states in their defence or logistical needs at the national and international level. It operates through the Heavy Airlift Wing (HAW) located in Papa Air Base in Hungary. The Polish AF used SAC’s C-17s to transport the bodies of the victims of the Presidential Tupolev crash in Smolensk in April 2010.[24] Sweden, on the other hand, used SAC for a very different purpose – to deliver cargo from Karlsborg Air Base to Mazar-e-Sharif in Afghanistan in September 2009.[25] This was HAW’s first mission done in support of ISAF. Swedish and Polish officers were also among the crew members during the first HAW mission performed in support of ISAF but without any Americans on board.[26]

Of course, none of the members in initiatives such as these has unlimited access to all the available resources. The share they get is usually proportional to their involvement. For example, the annual total of flying hours available under SAC is 3,165, which is divided among the 12-member nations. Both Poland and Sweden have entirely different shares equalling, respectively, 4.7% and 17.6%.[27] That gives 148.8 flying hours to be used by the Polish AF and 550.7 by the Swedish.

Red versus Blue
A Swedish JAS-39 Gripen returns to the play areas of the Arctic Challenge exercise over Norway, after taking on fuel from a U.S. Air Force KC-135R Stratotanker on 24 September 2013. (Source: Wikimedia)

Conclusion

This article has discussed some of the challenges confronting small air forces and whether multinational initiatives can increase their capabilities with specific reference to the Polish and Swedish AFs. The answer is yes. First, the examples discussed show that these projects are successful tools in building and strengthening capabilities such as AT, ISR and AAR. For small air forces, multinational cooperation gives an opportunity to develop these three areas to the extent that could not be afforded otherwise, or that would incur much higher costs.

Second, it is not only the pooled and shared fleets that the participating air forces can benefit from, but also training. The aircrews delegated to take part in any multinational initiatives return home with the experience they would often not have had a chance to develop otherwise. Here, it is also worth mentioning, that, along with pooling and sharing arrangements there are also programmes designed specifically for training purposes. These programmes present an excellent opportunity for air forces, especially the small ones, to exercise together towards capabilities that, in their home country are not available at all, or that are available but on an insufficient scale. Examples of such initiatives are the European Air Transport Training (EATT), and the European Advanced Airlift Tactics Training Course (EAATTC) started in 2012 and 2014 under the umbrella of the European Air Transport Fleet programme. The Polish AF has participated in both training initiatives in 2016 and 2017 while in 2015 it held observer status in EATT. Sweden also took part in EATT in 2013 and 2015 and was an observer nation in 2014. Another prominent example of a training arrangement involving the Swedish AF is the Cross-Border Training programme established in 2009. This project brings together Sweden, Norway and Finland and enables their air forces to use each other’s airspace to train together on a weekly basis.

Third, involvement at the multinational level in different forms of cooperation – pooling and sharing arrangements, expeditionary missions, air policing, and exercises, gives credibility to small air forces. The more often they work together with other nations, the more they will be perceived as a valuable and reliable potential partner. At the same time, such involvement requires certain work to be done, for example, making sure that one’s air force and its procedures, equipment, personnel’s knowledge, and abilities, are interoperable with potential partners in a coalition. This may incur additional costs, which may be challenging for small air forces.

Finally, while they appear very appealing, it must be remembered that multinational initiatives are not the panacea for capability gaps. For example, in many cases, a country only receives in return what is proportional to one’s contribution. Therefore, the multinational projects allow for the new capabilities to be built but on a limited scale and according to one’s financial input. As a result, collective capability development should not replace national ones. All European air forces, including the small ones, still need to develop their national capabilities. Multinational, collective arrangements may complement them, but they should never replace them altogether.

Maria Ewa Burczynska is a PhD candidate in the School of Politics and International Relations at the University of Nottingham where she is affiliated with the Centre for Conflict, Security and Terrorism. Her primary area of interest is European air forces and their participation in multinational operations and initiatives. She is also interested in the subject of disaster management as another dimension of national security.

If you would like to contribute to From Balloons to Drones, then visit our submissions page here to find out how.

Header Image: A Saab AJS-37 Viggen of the Swedish Air Force Heritage Flight on display at the RAF Waddington air show in 2013. (Source: Wikimedia)

[1] See, Sanu Kainikara, At the Critical Juncture. The Predicament of Small Air Force (Canberra: RAAF Air Power Development Centre, 2011).

[2] SIPRI Military Expenditure Database 2017.

[3] ‘Europe’ in The Military Balance, 115:1 (2015), pp. 57-158; ‘The Alliances and Europe’ in The Military Balance, 90:1 (1990), pp. 44-96.

[4] Ibid.

[5] Barre R. Seguin, Why did Poland choose the F-16?, The Marshall Center Occasional Paper Series (Garmisch-Partenkirchen: The George C. Marshall European Center for Security Studies, 2007), p. 6.

[6] Richard A. Bitzinger, Facing the Future. The Swedish Air Force, 1990-2005 (Santa Monica, CA: RAND, 1991), pp. 13-5.

[7] Rafał Ciastoń et al, Siły Zbrojne RP – stan, perspektywy i wyzwania modernizacyjne (Warszawa: Fundacja im. Kazimierza Pułaskiego, 2014), p. 54.

[8] Bitzinger, Facing the Future., pp. 11-4; Försvarsmakten, Flygvapnet.

[9] Bitzinger, Facing the Future., pp. 37-45.

[10] Zbigniew Średnicki, ‘Modernizacja techniczna sił powietrznych,’ Przegląd Sił Zbrojnych, 3 (2015), pp. 8-15.

[11] ‘Europe’ in The Military Balance, 118:1 (2018), pp. 65-168.

[12] Elizabeth Quintana, Henrik Heidenkamp and Michael Codner, Europe’s Air Transport and Air-to-Air Refuelling Capability: Examining the Collaborative Imperative, RUSI Occasional Paper (August 2014), p. 6.

[13] ‘Europe’ in The Military Balance, 118:1 (2018), pp. 65-168.

[14] Ibid.

[15]European multirole tanker transport fleet takes shape,’ European Defence Agency, 19 December 2014.

[16] ‘Europe’ in The Military Balance, 118:1 (2018), pp. 65-168.

[17]Alliance Ground Surveillance (AGS),’ North Atlantic Treaty Organisation, updated 6 June 2017.

[18] Grzegorz Hołdanowicz, ‘Nieprimaaprilisowe pożegnanie z AGS,’ Raport – Wojsko Technika Obronność, May 2009.

[19] Tadeusz Wróbel, ‘Tysiąc lotów AWACS-a nad Polską,’ Polska Zbrojna, 13 October 2016.

[20] Quintana et al, Europe’s Air Transport and Air-to-Air Refuelling Capability, p. 11.

[21] Colonel in the Polish Air Force and a scholar at the National Defence University in Warsaw, interview conducted by the Author on 30 June 2016.

[22]MCCE support to Arctic Challenge 2017,’ Movement Coordination Centre Europe, 29 May 2017.

[23] Juliusz Sabak, ‘Rosyjskie An-124 nadal wożą sprzęt NATO,’ Defence 24, 13 January 2017.

[24] Colonel in the Polish Air Force and a scholar at the National Defence University in Warsaw, interview conducted by the Author on 22 June 2016.

[25]SAC Milestones 2006 –,’ Strategic Airlift Capability.

[26] Ibid.

[27]The Strategic Airlift Capability (SAC),’ Strategic Airlift Capability.

Hybrid Warfare, the Electromagnetic Spectrum, and Signposts for #highintensitywar

Hybrid Warfare, the Electromagnetic Spectrum, and Signposts for #highintensitywar

By Squadron Leader Jimmy

Editorial Note: Between February and April 2018, The Central Blue and From Balloons to Drones, will be publishing a series of articles that examine the requirements of high-intensity warfare in the 21st Century. These articles provide the intellectual underpinnings to a seminar on high-intensity warfare held on 22 March by the Williams Foundation in Canberra, Australia. In this article, Squadron Leader James Owen of the Royal Australian Air Force examines the importance of fully exploiting the electromagnetic spectrum in future high-intensity war.

The introduction in 1915 of the so-called ‘interrupter’ gear allowed pilots to fire a machine gun through the propeller arc of First World War combat aircraft. This was a decisive change; pilots could now find and track targets in their field of view, assess their situation, manoeuvre their aircraft and engage threats with some degree of accuracy. Find, track, assess, manoeuvre and engage.

This critical development turned aircraft into competent air-to-air combat machines that could have a significant effect in their contemporary battlespace. Presently, and moving into the future, high-intensity warfighting operations against a peer adversary will require a level of dynamic joint and combined integration in the electromagnetic spectrum (EMS) that is akin to an organisational interrupter gear. The electromagnetic interrupter gear will need to synchronise spectrum requirements for communications, radars and precision navigation and timing as well as requirements for understanding what the similar threat systems are doing, and the conduct of offensive electronic warfare to degrade and disrupt the threat’s use of the spectrum. The Australian Defence Force (ADF) and its allies will need to be able to find and track threats in the EMS, assess their future courses of action, manoeuvre both physically and in the EMS and engage through the most appropriate warfighting domain. Find, track, assess, manoeuvre and engage.

Potential threat nations learned from the West’s way of war after the 1990-1991 Gulf War, and the 1999 Kosovo air campaign; the strength of Russian, Iranian, and Chinese integrated air defence systems are a testament to this. Similarly, potential threat actors have observed the West’s recent campaigns and adapted to meet them. Threat actors are exploiting the ‘grey zone’ that precedes a declared conventional war; they have sophisticated approaches for leveraging multi-domain effects to achieve their objectives. Experiences from Syria, Ukraine and the South China Sea demonstrate that the ‘unconventional’ and hybrid are now conventional and will be part of the reality of high-intensity warfare. The presence of proxy, paramilitary or deniable forces of little green men or little blue men, an array of remotely controlled or robotic threats and a complex multi-pronged contest in the EMS should now be assumed in high-intensity warfare, and the grey zone of conflict escalation that precedes it. It is therefore valuable to review some significant themes in recent campaigns to identify signposts for the role of EMS operations in high-intensity warfare.

20180123raaf8165233_073
EA-18G Growlers from No. 6 Squadron RAAF arrive at Nellis Air Force Base, Nevada, for Exercise Red Flag 18-1, 2018. (Source: Australian Department of Defence)

Manoeuvre in the Electromagnetic Spectrum can be Decisive in the Physical Domain

Much has been written elsewhere over the last decade about the ‘unconventional’ threat that western militaries faced in Afghanistan, Iraq, and Syria. Western militaries were caught on the hop by the proliferation of improvised threats that exploited the EMS, particularly during the initial counter-insurgency campaigns in Iraq and Afghanistan. Remote controlled improvised explosive devices (IEDs) had a huge impact on the approach to manoeuvre by western forces. IEDs targeted the strategic centre of gravity of the West; casualty numbers. Arguably the constraints that these devices placed on the ability of western forces to manoeuvre at will in the physical domain and engage freely with the population had a strategic impact on the course of those wars. Behind the explosions, there was an unforeseen and dynamic battle of cat and mouse in the EMS. There is a significant amount written elsewhere about the importance of being able to ‘manoeuvre in the Electromagnetic Spectrum’; the IED contest is a useful and tangible lesson in what that phrase means. As IED makers developed new means of activating IEDs remotely, western forces developed jammers to defeat those devices; the IED makers then quickly adapted to another remote device in another part of the spectrum, and the dance continued.

Control of the Air depends on Control of the EMS – Examples from Hybrid Warfare

The Air Power Manual, AAP-1000D, Australia’s current capstone air power doctrine, defines Control of the Air as ‘the ability to conduct friendly operations in all three dimensions without effective interference from enemy air power.’ Recent and ongoing conflicts have demonstrated that the air is now contested through an array of remotely controlled and robotic devices; to defeat those devices requires an equivalent ‘Control of the EMS’.  The following examples will explore some recent examples that signpost the requirements of EMS operations in a high-intensity conflict.

In January 2018, non-state actors conducted a co-ordinated strike mission against Russia’s Khmeimim air base in Syria with a total of 13 improvised unmanned air systems (UAS). According to the Russian Ministry of Defence, all the UAS were ‘detected […] at the safe distance (sic) from the base’ and neutralised without hitting their target. Control of some of the UAS was ‘seized’ by Russian ‘Electronic Warfare hardware’ which forced them to land; short-range air defence systems destroyed some. The Russian Ministry of Defence indicated that they used a layered system of multi-domain air defence that integrated EW and air defence batteries.

Ironically, this kind of unconventional targeted strike seems to have learned from and built upon the tactics recently employed with devastating success against ammunition dumps in Eastern Ukraine. In those instances, the actor that conducted the attack is not clear or declared. The attacks were reportedly conducted by unidentified drones which dropped Russian thermite grenades onto their targets.  The results indicate that the Ukrainian armed forces either could not find and track these drones, or the ability to engage them to prevent the successful conduct of their missions. It is possible that they had neither.

In both examples non-state, proxy, or deniable forces demonstrated intent and capability to deliver effects through the air to disrupt logistics and operations in depth. In the Syrian example, the Russians demonstrated that control of the EMS contributes significantly to control of the air in hybrid warfare; the Ukrainian example demonstrates that the absence of at least one essential part of the EMS interrupter gear undermines control of the air.

In February 2018, an Iranian ‘Saeqeh’ UAS conducted an incursion into Israeli airspace and was engaged and destroyed in around 90 seconds after crossing the border by AH-64 Apaches. This event has an interesting history that is very useful for understanding the relevance of effective EMS operations in high-intensity warfare. The ‘Saeqeh’ UAS itself is a clone of the US RQ-170 UAS. This cloning was made possible for Iranian defence and industry through an opportunity to reverse engineer a US RQ-170 low observable UAS that landed in Iran while on a reconnaissance mission in 2011. The Iranians claim that they forced that RQ-170 to land through a combination of datalink jamming and GPS spoofing by their EW Force, which fooled the RQ-170 into landing in Iran. Regardless of the truth in that event, the techniques that the Iranians claim to have used are plausible and point again to the role of EMS operations in control of the air.

Following the reverse engineering of the RQ-170 outlined above, the subsequent clone, called the ‘Saeqeh,’ conducted an incursion of Israeli airspace on February 18. The Israeli Defence Force (IDF) reported that they were able to track the ‘Saeqeh’ throughout its mission from its launch site near Palmyra in central Syria. It is not clear how this tracking was achieved, but it was almost certainly through the EMS through an electronic signature. Based on this tracking information the IDF assessed the route of the UAS and manoeuvred AH-64 Apaches to wait for it when it crossed into Israel. The Apaches engaged and destroyed the Saeqeh. Based upon the active exploitation of information from the EMS and integration with operations the IDF was able to find, track, assess, manoeuvre and engage in neutralising this UAS; in this case with kinetic effects.

These RQ-170 and Saeqeh examples took place in the legal and political grey zone of armed conflict; the US and Israel, Iran and Syria are not in a formally declared war, and the borders are static. In both cases, it is likely that the defenders knew enough about the presence and nature of the UAS in question to have anticipated its activity and prepared a response; one kinetic, one non-kinetic but both appropriate responses based upon the fact that the engagements took place in the defender’s airspace. These scenarios were very predictable for all sides and not a complex or dynamic operational EMS challenge. In both circumstances, the ‘penetrating’ nation attempted to exploit low-observability and control of UAS through the EMS to achieve control of the air sufficient to achieve their mission. In both cases, the superior exploitation of the EMS by the defending force enabled them to maintain control of the air in their airspace.

It is apparent from the examples above that both the Russians and the Israelis demonstrated control of the air sufficient to defeat the threat that they faced. They both demonstrated that they have been able to manoeuvre both physically and, in the EMS, to meet their threat. They were able to find, track, assess and engage with EW or kinetic effects. It is apparent that the Ukrainian armed forces did not have Control of the Air sufficient to defeat the UAS attack through either kinetic or EMS effects and suffered the devastating success of the attack as a result.

The Russian and Israeli EMS ‘interrupter gears’ in these situations demonstrated an ability to anticipate and address threat manoeuvre in the EMS. It is important to recognise that the EMS environment that these defensive systems faced were essentially predictable and informed by several opportunities to understand the pattern of activity and character of their threat in the EMS. Aside from the UAS involved, the defensive forces that were involved or affected by these EMS operations were also largely static and well established. The respective Iranian and Israeli EMS command and control then only needed to deal with an EMS threat that could evolve or change over time periods such as weeks or months.

EMS Operations in High-Intensity Warfighting

In future high-intensity warfare, EMS operations are likely to be more complex than the scenarios above, but they will be an extension of the same themes and activities. The operating environment itself is likely to be more dynamic with a broad range of manoeuvring actors in the area. A peer adversary is likely to attempt to conduct multiple coordinated incursions into friendly airspace and territory with a broad range of remote weapon systems, many of which will use data links, sensors and transmitters that are hard to detect, characterise and track. The joint force will need to counter these across a coalition through integrated command and control of effects across the EMS and the warfighting domains. High-intensity warfighting will place extraordinary demands on the EMS interrupter gear, which will be critical to the success of operations by the joint and combined force.

A Way Ahead for ADF EMS operations

The solution for EMS operations is not just a technological one; effective EMS operations will also require significant evolutions in doctrine, organisation and training. For the former, the US has developed a doctrinal concept that they call ‘Joint Electromagnetic Spectrum Operations’ (JEMSO). JEMSO is a strategic ‘top-down’ concept. JEMSO should create a common lexicon and a joint ‘umbrella’ framework for the US services to integrate their service-specific structures and approaches to EMS into a common command and control system at the joint force level. The ADF will similarly need an ability to conduct this integrated command and control of EMS operations on its own and to be interoperable with the US framework.

Organisationally, the ADF will need to adapt the joint force so that it can integrate, plan, and execute EMS operations. To properly exploit the potential of the EA-18G Growler and future electronic warfare (EW) capabilities, the ADF will need EMS Operations cells in operational and tactical level joint and single-domain headquarters. High-intensity warfare will demand that this capability is networked and synchronised throughout the joint force.

Innovation, Acquisition, and the EMS

It is not just the operational force that requires adaptation to meet the requirements of high-intensity warfare in the EMS. Threat evolution requires rapid development, acquisition, and integration of new technologies into the force. Intelligence will need to be geared to keep ahead of this threat and to inform the direction of capability management. To keep ahead of the threat, technological development and innovation will need to leverage the ideas of industry, academia and Australia’s own Defence Science and Technology Group; threat capabilities and warfighter requirements should lead this, not the availability of technology. To achieve sufficiently cutting-edge technology, this requires an agile acquisition system. A heavy appetite for innovation risk will be required; we should be prepared for projects to ‘fail’ when developing cutting-edge technologies, without seeing the activity as a failed effort.

Davis 29
Hunter killer group of F-105G Wild Weasels and F-4Es take fuel on the way to North Vietnam for a LINEBACKER strike in the summer of 1972. (Source: National Museum of the US Air Force)

Innovation and technological solutions will need to be lockstep with the warfighter to ensure that the appropriate training, tactics, and procedures (TTPs) are developed by services or the joint force to introduce them to service. My previous review of The Hunter Killers highlighted the incredibly high casualty rate suffered by the first Wild Weasel surface-to-air missile hunting squadrons; half of the aircrew of the first squadron was killed-in-action. Within the early Wild Weasel programmes, technological developments were poorly integrated with intelligence for the warfighter which manifested in weak tactics development before their initial deployments. The high mortality rate is a testament to this lack of integration. To avoid a similar fate, the joint force will need a means of rapidly developing, prototyping, and fielding new technologies and a coherent means of integrating intelligence-led TTPs development to employ them effectively.

Train the Force to Operate in the EMS

Technological solutions can enable us to move EW effects to the frequency band that the threat is in, but only education and training can deliver the ‘skill and care’ necessary for effective EMS manoeuvre. The effective conduct of EMS operations needs educated warfighters that understand not just the technical aspects of this contest, but the operational concepts and inter-relationship with the other warfighting domains.

The Russian military has integrated EW capabilities throughout their forces:

It’s found throughout every arm of service, every branch of service, it’s almost impossible to avoid EW capability, which very much contrasts to western militaries.

Russian EW activity is integral with but not subordinate to signals intelligence, cyber and conventional combat capabilities. Along with the distinct operational advantages of EW integration into combined arms units and formations, this has a significant second-order effect; Russian officers become familiar and comfortable with the integration and use of EW at a very early stage of their career. They train to fight in and with it. Education provides warfighters with the understanding to identify operational changes and adapt promptly; most significantly it enables warfighters with the ability to adapt to unique and unforeseen circumstances in an innovative but logical fashion.

The ADF does not have such familiarity with EW within the joint force. It will require a new cadre of EW generalists throughout the force that can assist in the integration of EW at the lowest level; it will also require specialist planners at the tactical and operational levels.

Summary

The examples above demonstrate clear patterns in the exploitation of the EMS by state and non-state actors in hybrid warfare; use of remote devices in land and air to attack high profile and high payoff targets at the front line and in the rear area should be assumed to be the new baseline threat in hybrid warfare. Non-state actors increasingly have access to ever more sophisticated capabilities. However, it is apparent that conventional forces in future high-intensity warfare will use a broad spectrum of remotely controlled devices in land, sea and air that have much better range, are much faster, agiler in the EMS and more destructive than their non-state peers.

JEMSO offers the ADF a suitable model to develop an organisational EMS interrupter gear and a vector for the supporting capability management and force generation structures that are required to underpin it. Dynamic joint force acquisition and capability management will be a vital element of preparing the ADF to win the EMS contest in high-intensity warfighting; however, and while it has not been considered in this article, it remains a truism that the human component is likely to be the key to winning or losing. Ultimately, the ADF will need appropriately educated and trained warfighters able to anticipate, integrate and exploit the EMS. Warfighters empowered with education in operations in and through the EMS will be the foundation of victory in #highintensitywar.

Find, track, assess, manoeuvre and engage.

Squadron Leader Jimmy is an officer in the Royal Australian Air Force. The opinions expressed are his alone and do not reflect those of the Royal Australian Air Force, the Australian Defence Force, or the Australian Government.

Header Image: Technicians from No. 6 Squadron RAAF perform an after flight inspection on an EA-18G Growler at Nellis Air Force Base, Nevada, during Exercise Red Flag 18-1, 2018. (Source: Australian Department of Defence)

From ‘Bats to MAVs’: The Concept is Clear, ‘Small’ is the Future of Aerial Warfare

From ‘Bats to MAVs’: The Concept is Clear, ‘Small’ is the Future of Aerial Warfare

By Sergeant Lee Tomàs

Editorial Note: Between February and April 2018, The Central Blue and From Balloons to Drones, will be publishing a series of articles that examine the requirements of high-intensity warfare in the 21st Century. These articles provide the intellectual underpinnings to a seminar on high-intensity warfare held on 22 March by the Williams Foundation in Canberra, Australia. In this article, Sergeant Lee Tomàs of the Royal Air Force (RAF) examines the implications of Micro Air Vehicles (MAVs) for future conflicts.

In 1941, a Pennsylvania dentist named Lytle S. Adams was on vacation in the South-West of America within the famous Carlsbad Caverns. While exploring Carlsbad’s vast expanse, he observed it hosted thousands of indigenous Bats. Adams was monumentally impressed by what he saw and then just as history has often taught us previously, the most remarkable ideas often derive from the strangest of places, at a random moment, when separate paths conjoin. Much like Sir Isaac Newton when the Apple hit his head, thus propelling him in founding the theory of gravity.[1] Adams’ similar ‘eureka’ moment did not derive from when he observed the Bats in Carlsbad’s deep and damp expanse; it was when he turned on his car radio when departing, which amplified that the Imperial Japanese Navy had devastatingly attacked Pearl Harbor. Adams at that precise moment began plotting an unorthodox plan of revenge against America’s new enemy; the Japanese, using what he had seen previously that day; the Bats.[2]

The idea that developed from Adams’ eureka moment was to attach incendiary material onto swarms of collected Bats, who previously (through the research and development stages of the idea) were trained to hibernate in large storage refrigerators. The final phase of Adams’ plan was for these Bats to be dropped from an aircraft in a bomb casing encompassing similar properties to the aforementioned refrigerators. These would then open mid-air, dispersing the Bats outwards onto Japanese cities below to seek warmth and sanctuary within enemy building structures, inside eaves and roofs, which during that period in Japan were made of highly flammable material. The Bats would then go kinetic, catch fire, and subsequently demolish their host building target.[3] Adams’ own words would describe the predicted results of the later titled Project X-Ray. ‘Think of thousands of fires breaking out simultaneously over a circle of forty miles in diameter for every bomb dropped.’ He later recalled that ‘Japan could have been devastated, yet with a small loss of life.’[4]

Adams’ creation of Project X-Ray could be perceived as pure lunacy to the untrained eye, however, with the present-day parameters of modern warfare constantly evolving, sometimes a little bit of lunacy can be effective in achieving the desired strategic aim. Adams’ premise of causing considerable amounts of effective damage upon one’s enemy, with the least amount of innocent lives taken, through the hostile deployment of these mini-warfare-vessels might, in the future, be a viable solution. Project X-Ray’s legacy, concept and its underpinning tactical peripherals of swarm-based aerial strategies will be forwarded within this narrative as still being relevant and possible within the delivery of modern warfare. This will be proven by substituting the Bats for the new technological assets: MAVs, which when deployed would give a modern force, like the RAF, a viable tactical equaliser and advantage within wider strategic operations.

Project X-ray principles of tactical swarm-based aerial attack have possible relevance within historic, present-day, and future western military operations due to two distinct and transcending reasons. The first is the current evolving development and procurement of military platforms and assets, which are now gravitating towards small, smart, and cheap technology that encompasses the ability to deploy in swarm formations. This ability includes overpowering your enemy within all areas through greater aerial deployments while retaining a cheaper overall financial outlay. The second reason is the potential future opportunity to reduce the amount of military and civilian deaths caused by historic and currently deployed air operations. Below we will explore these two reasons in depth while answering if aspects of Adams’ idea could be implemented within future UK warfare scenarios by using the vast range of MAV technology available and placing them in historical conflict case studies, which will position how they will affect future air-centric operations globally.

As a platform, MAVs are a small remotely, or autonomous air-asset. Typically, they exist in three size classifications; small, medium, and large. This article focusses on small and medium-sized MAVs. Small MAVs, which the US Department of Defense defines as being 20lbs or lighter, are typically hand sized, like the U.S ‘Cicada,’ which is a Covert Autonomous Disposable Aircraft used for carrying out undetected missions in remote battlefields.[5] Medium MAVs are typically ‘dinner-plate’ sized like the ‘Quad,’ ‘Hexa’ or ‘Octo’ copters, currently used by UK police forces for surveillance operations within the airspace of airports like the ‘Aeryon-Skyranger’ drone.[6] There are also large MAVs like the ‘Harpey’ Drone, which is currently used by the Chinese military and has a nine-foot wingspan and 32 Kilogram warhead payload that is guided by radar, can loiter in the air and can deploy with 17 others systems from a single five-ton truck.[7]

102691538-Unknown.1910x1000
The US Navy’s “CICADA” drone program is producing lightweight disposable glider drones for field missions. (Source: US Naval Research Laboratory)

This article will start where the Bats ended. Although the aforementioned ‘Project X-Ray’ was not implemented operationally during the Second World War, its premise – to inflict regional mass damage to Japanese cities without mass fatalities – is a tactic that is still desired today by the majority western militaries and governments. The Cicada as an individual platform has the same tactical properties and potential as Adams’ Bats in that they can be deployed en-masse, equipped with small thermobaric NANO munitions, which could easily perform the small kinetic solution positioned during the Project’s design stage, and are also more importantly incredibly small. The potential capability of this MAV within a swarm configuration has already been adopted again by the US Air Force (USAF) when it deployed ‘Tempest’ tactical balloons at high altitude. These then released medium Tempest MAVs who during mid-flight then distributed smaller Cicadas MAVs en-masse (again all at high altitude) to collect environmental data.[8] A more warfare centric illustration of Cicada’s possible capability was demonstrated during the recent deployment of 103 ‘Perdix’ MAVs from an American F/A-18 fighter jet, which once deployed (mid-air) flew to three different target locations and simulated a swarm attack scenario on each designated enemy position. A Chinese civilian corporation who specialises in MAV development had also illustrated this possible small-MAV swarm scenario when it deployed 67 MAV’s simultaneously which performed a ‘saturation’ attack on an enemy anti-aircraft battery, subsequently neutralising the anti-air threat. The U.S Navy has also recently reinforced the effectiveness of mass MAV strategy when it deployed 8 LOCUST (medium) MAVs simultaneously towards one Aegis-class destroyer warship (the most effective global air-defence system currently available).[9] This exercise resulted in 2.8 of the 8 MAVs penetrating the ships defence system, causing subsequent damage and the conclusion that if this deployment were increased by 10 or a 100, the consequences would be more devastating, proving that smaller, smarter and more lethal technologies are the future of air-centric warfare.

The potential benefits of these attacks can be dissected further. The Bat inspired slow-burn-combustion Cicada MAV attack would, as Adams conceived initially, cause the necessary damage to enemy territory, buildings, and infrastructure while reducing the human-centric ‘collateral damage.’ This reduction in lives taken by this type of operation (if appropriately deployed) would achieve its aim by allowing the residing population the choice to flee their residencies and disperse the area, therefore allowing a secondary larger tactical air-strike to occur on key infrastructure targets like nuclear reactors, power stations and government/military buildings. If civilian dispersal was not forthcoming then maybe using MAVs to deploy dispersal gas, or even recorded PA warnings played through speakers on the MAV’s could be utilised. The former ability already exists and was demonstrated by the Skunk MAV, which were bought by a South African Mining company which deployed 25 of these (medium) multi-rotor MAVs to quell potential protester uprisings. Skunks have four barrels which fire pepper-spray or paintball rounds at protesters. Less potent aerosols could potentially be designed to encourage the necessary civilian movement and dispersal passively.

This above mentioned strategy would in the first instance reduce the mass-death scenario created from current air-strike strategies, and also decrease the erosion of a state’s global-moral currency, a process which was demonstrated when the US disclosed 116 innocent civilians were killed through its UAV centred strategy in Afghanistan in 2016, and in response culminated in extensive global condemnation.[10] The erosion of a state’s moral-currency is not outwardly/globally post-strike, it is also internally eroding within the conflict itself as air-strikes can have an extensive degrading effect on the local population, which has historically been the catalyst for the worlds emerging and multiplying insurgencies in Middle Eastern conflicts.[11]

It Always Comes Down to Money!

From a fiscal perspective using small MAVs as weapons could also be highly beneficial in future tactical strikes. MAVs as a platform can now be designed and created using additive 3-D printing. Within the West geographically, 3D printing has already transcended into the world of MAVs through pioneers such as Andy Keane and Jim Scanlan from the University of Southampton University, who, through 3-D printing, produced a drone with a five-foot wingspan. This process has further expanded globally through the online ‘Maker movement’ which shares 3D drone designs and do-it-yourself guides for anybody who wishes to construct a Drone. Ang Cui, a Columbia University PhD, also has a ‘Drones at home’ blog with step-by-step instructions for would-be drone makers to follow. The first commercial and military MAV produced at scale through 3D printing was the small ‘Razor’ drone, which is not only highly effective but can be printed in one day in the US for $550 there are also cheaper variants which cost $9 per unit.[12]

The Razor’s wingspan of forty inches, cruise potential of 45mph and a flight capability of forty minutes comes in complete form for $2,000, and its production company MITRE believe future projects will arrive under $1,000, or cheaper as the MAV market expands.[13] Further evolutions include Voxel8 a 3D electronic printing company whose $8,999 3-D printer can print an operational drone with electronics and engine included.[14]

Commercial American companies have also illustrated the MAV mass production potential of 3D technology, such as United Postal Service (UPS) who have established a factory with 100 3-D printers, which accepts orders, prints them, allocates a price, and then ships them the same day. Furthermore, UPS plan to increase its plant size to 1000 printers to support major production runs.[15] China has also recognised the benefits of embracing civilian technological advancement to improve military procurement. The expansion of 3D printing within China’s commercial sector has recently empowered its military to evolve its procurement of warfare assets and platforms effectively. This was demonstrated to observing media by the Chinese Army who repaired a broken military class oil-truck in an austere battlefield environment using only a single 3D additive manufacturing machine. This process allowed the crew to replicate and replace the unserviceable components both on-site and within a short period.[16] Furthermore, this demonstration revealed the ease, skill, convenience and reliance China places on 3D printing, which in this instance prevented them experiencing routine operational issues like losing their re-fuelling capability, the requirement for a truck recovery team to deploy and the need to wait for an expensive part from a geographically distant manufacturer to arrive. A final and more strategic advantage this 3-D process has provided is removing China’s potential reliance on global commercial industry to provide these technical parts en-masse as the US does within its own present-day military procurement cycles.

Not only does 3D printing provide numerous tactical and speed efficiencies, but it could also, if correctly exploited, arrive at an incredibly cheaper cost financially. Using the Razor as an example, it currently costs $2000 per individual platform (complete). Therefore, a smaller Cicada MAV would arrive if produced within the same process at $250 or cheaper due to its smaller size, reduction of material required and after necessary production efficiency has been achieved.[17] Once assembled, if a small incendiary were then attached at an estimated cost of $200, it would make the platform an incredibly cheap and deadly weapon. This overall manufacture-to-deployment financial pathway compares favourably to the recently released UK Ministry of Defence figures that an average Tornado aircraft operational flight costs £35,000-per hour. This figure, when plugged into an operational scenario, creates the following financial outlay; two Tornados performing a six-hour (one stop) strike operation carrying four Paveway bombs (£22,000) and two Brimstone missiles (£105,000) would cost on average £1 Million. If the Paveway munitions were later exchanged for the Storm-Shadow munition variant (£800,000), the cost would increase exponentially.[18] This price, even without the latter munition, would allow you to purchase 2,000 Cicada’s with the ability to be dropped from a more fiscal efficient platform and would then as a swarm fly straight to the target area with a potential kill radius of 2 metres per MAV depending on incendiary attached. This type of attack would reduce the possibility of human collateral damage, firstly from a surface-to-air threat to the pilot and innocents on the ground exposed to the aerial kill-chain, while giving the swarm operator the ability to increase or decrease the swarm size depending on the amount of damage desired or required. The financial benefits continue to expand in favour of small MAVs when they are compared to rival high-technology air platforms like the fifth generation F-35. Using the previous larger Razor MAV as an example; it costs $2,000 per fully functioning drone, which when compared to the cost of 16 F-35s would allow you to purchase for the same price one million Razors. If the F-35s and these Razors were then deployed against each other in active hostile deployments, the Razors would retain the tactical potential if designed correctly to swarm the 16 F-35s, destroying them, even without incendiaries, through intended foreign object debris damage. Therefore, eradicating the superiority that the F-35 previously held. Of course, scenarios, testing and system advancement would dictate these hypothetical scenarios, however as all the scenarios suggest there is a new dimension in modern warfare and it is the MAV.

Sergeant Lee Tomàs is a Senior Non-Commissioned Officer in the Royal Air Force. In a 13-year career in the RAF, he has deployed to the Falkland Islands, Afghanistan, Cyprus, Oman, and Cyprus. He holds a Post Graduate Certificate from Brighton University, an MA from Staffordshire University, and an MA from Kings College London. He runs a political online blog and lecture series at RAF stations which tries to develop junior Ranks knowledge of current affairs. In 2017, he won the prestigious CAS ‘Fellow of the Year’ award.

Header Image: A Honeywell RQ-16 T-Hawk Micro Air Vehicle flies over a simulated combat area during an operational test flight, c. 2006.

[1] Steve Connor, ‘The Core of truth behind Sir Isaac Newton’s Apple,’ The Independent, 18 January 2010.

[2] Alexis C. Madrigal, ‘Old, Weird Tech: The Bat Bombs of World War II,’ The Atlantic, 14 April 2011.

[3] David Hambling, Swarm Troopers: How Small Drones Will Conquer the World (London: Archangel Ink, 2015).

[4] Madrigal, ‘Old, Weird Tech: The Bat Bombs of World War II.’

[5]  Sarah Kreps, Drones: What Everyone Needs to Know (Oxford University Press, 2016); Anon, ‘U.S. military hopes to enlist tiny, durable Cicada mini-drone,’ The Japan Times.

[6]  Anon, ‘UK Police ‘Skyranger’ Drones to patrol skies above Gatwick airport after major disasters,’ The Huffington Post, 13 March 2014.

[7] John Kaag and Sarah Kreps, Drone Warfare (London: Polity Press, 2014), p. 49.

[8]  Ibid, pp. 8-9.

[9] David Hambling, ‘U.S. Navy Plans to Fly First Drone Swarm This Summer’, Military.com, 4 January 2016.

[10] Spencer Ackerman, ‘Obama claims US drone strikes have killed up to 116 civilians,’ The Guardian, 2 July 2016.

[11] Jason Berry, ‘Inside Americas Drone War, a moral Black Box,’ PRI, 26 September 2012.

[12] T.X. Hammes, ‘The Future of Warfare: Small, Many, Smart vs. Few & Exquisite?,’ War on the Rocks, 16 July 2014.

[13] Hambling, Swarm Troopers, pp. 109-10.

[14] Dario Borghino, ‘Voxel8 paves the way for 3D-printed Electronics,’ New Atlas, 14 January 2015.

[15] Eddie Krassenstein, ‘Cloud-DDM-factory with 100 (eventually 1000) 3D printers & just 3 employees’ open’s at UPS’s Worldwide Hub,’ 3DPrint.com, 4 May 2015.

[16] Simon, ‘Chinese military begins using part production library for 3D printing replacement parts in the field,’ 3ders.org, 12 August 2015.

[17] Mariella Moon, ‘Watch how the Navy plans to deploy its tiny Cicada drones,’ Engadget, 22 May 2015.

[18] Alistair Bunkall, ‘How Much Will Airstrikes on IS Cost Taxpayer?,’ SKY News, 26 September 2014.

Tactical Reconnaissance Redux? The Requirement for Airborne Tactical Reconnaissance in #HighIntensityWar

Tactical Reconnaissance Redux? The Requirement for Airborne Tactical Reconnaissance in #HighIntensityWar

By Squadron Leader Rodney Barton

Editorial Note: Between February and April 2018, The Central Blue and From Balloons to Drones, will be publishing a series of articles that examine the requirements of high-intensity warfare in the 21st Century. These articles provide the intellectual underpinnings to a seminar on high-intensity warfare held on 22 March by the Williams Foundation in Canberra, Australia. In this article, Squadron Leader Rodney Barton examines and discusses the importance of tactical level reconnaissance in support of operations in a contested environment. In examining the importance of such a capability, Barton makes a case for the Royal Australian Air Force (RAAF) to reacquire the ability to undertake such missions.

The Australian Defence Force (ADF) has not maintained an airborne tactical reconnaissance capability since the retirement of the reconnaissance variant of the F-111 in 2010. Instead, the ADF has shifted focus to ‘traditional’ intelligence, surveillance, and reconnaissance (ISR) platforms such as the P-8 Poseidon and G550 Gulfstream aircraft, with unmanned ISR capabilities soon to follow. These platforms are not designed to operate in a contested environment; a degree of air superiority is required to ensure optimised collection. The ADF has been comfortably reliant on satellites to penetrate denied areas that require imagery collection, but the emergence of counter-space capabilities now puts this access at risk. This article will discuss the role of airborne tactical reconnaissance, why it still exists, why the ADF needs a tactical reconnaissance capability and the innovative methods of applying tactical reconnaissance in small air forces like the RAAF.

For as long as airframes have existed – the airborne reconnaissance role has existed. From the very first balloons in the nineteenth century through to the modern age, aircraft have flown in the vicinity of the adversary to understand their posture and intentions. Tactical reconnaissance aircraft have developed gradually with speed and altitude to penetrate defended airspace and gain access to sensitive areas. These aircraft were typically unarmed to maximise their operating speed, height, range and most importantly, survivability. At times during the Second World War, a lack of dedicated tactical reconnaissance assets necessitated modifications to existing fighter aircraft to meet the collection requirement. This specific mission was known as ‘dicing’ – short for ‘dicing with death’ – due to the risk the aircraft faced while conducting the mission, particularly the post-strike bomb assessment. During the Cold War, the tactical reconnaissance mission took on a strategic reconnaissance focus epitomised in the US by the U-2 Dragonlady and SR-71 Blackbird respectively. The advent of a satellite imagery capability led to less reliance on these platforms for strategic collection – although the U-2 remains in service and high demand, albeit in permissive airspace.

HU 92977
A vertical serial reconnaissance photograph, taken from 24,000 feet, showing the St Jean district of Caen, France. This area was destroyed by two heavy raids on the city by aircraft of No. 5 Group, RAF Bomber Command, on the nights of 6/7 and 12/13 June 1944. The Bassin Saint-Pierre is at bottom left and the River Orne flows from upper right to middle left. The church of St Jean, damaged but still standing, is visible towards the middle of the lower-right quarter of the photograph. Another badly damaged area can be seen across the river in the Vaucelles district, to the right of the main railway station (top left). (Source: © IWM (HU 92977))

Despite the developments of space-based imagery and high-altitude collection platforms, the requirement for tactical reconnaissance in the US remained evident during the Vietnam War and the First Gulf War. The US Air Force (USAF) operated several modified fighter aircraft (RF-101 Voodoo and RF-4C Phantom) and aircraft-launched drones during the Vietnam War, particularly for the collection of target intelligence and post-strike assessment. RF-4C Phantom aircraft continued to serve through the First Gulf War providing vital intelligence on Republican Guard movements and Iraqi Air Force disposition. They were also misused to a certain degree, in the bid to find and fix Iraqi mobile missile launchers. The inability to view or disseminate the imagery real-time from the venerable Phantoms no doubt compounded this issue. The USAF retired the RF-4C in 1995 and has not sought a replacement since – most likely due to the emergence of unmanned ISR platforms and reliance on space-based assets.

Advances and growth in satellite imagery collection, along with the increasing sophistication of ground-based air defences, have challenged the utility of tactical reconnaissance. Not only do imagery satellites collect more persistently against denied areas, but they are not subject to air defence systems which increasingly have greater reach and lethality. The shoot-down of a Turkish RF-4E in Syrian airspace in 2012 highlights the threat that air defence systems pose. Despite these factors, countries with small air forces still invest and implement airborne tactical reconnaissance capabilities. Why? The simple answer is cost, access and availability. Not every country has access to satellite imagery. Even when they do, the imagery may not be available when it is required due to weather, communications, or other priorities. Given satellite’s strategic nature and scarcity, a local commander’s tactical requirements may be lost amongst national strategic priorities. Tactical reconnaissance missions can be employed locally and responsively to support immediate requirements.

Local control and accessibility are two key reasons why the US Navy (USN) still operates a tactical reconnaissance capability through the Shared Reconnaissance Pod (SHARP) carried on the F/A-18F Super Hornet aircraft. For a deployed carrier battle group operating in a potentially contested environment, satellite imagery will not be on tap for perusal. Many European and Middle-Eastern nations have also invested in tactical reconnaissance capabilities due to their low cost and accessibility of the imagery collected. Podded electro-optical/infra-red sensors such as the DB-110 (a tactical derivative of the U-2 sensor) have proven popular in these countries due to their platform agnostic versatility with carriage options on the F-16 Fighting Falcon, GR-4 Tornado, or F-15 Eagle. The DB-110 can collect almost 26,000 square kilometres of imagery per hour from a stand-off range of 150 kilometres. Low cost, seamless pod integration onto fighter platforms and flexibility of use provide significant benefits to small air forces that cannot afford to invest heavily in ISR space or air-breathing assets.

030113-N-2385R-008
A Shared Reconnaissance Pod (SHARP), installed on the bottom of an F/A-18F Super Hornet assigned VFA-41, is positioned on the USS Nimitz’s flight deck waiting to be launched during the next cycle of flight operations, c. 2003. SHARP is a multi-functioned reconnaissance pod, adaptable to several airborne platforms for tactical manned airborne reconnaissance. It is capable of simultaneous airborne and ground screening capabilities and was designed to replace the US Navy’s Tactical Airborne Reconnaissance Pod System. (Source: Wikimedia)

Further advances in tactical reconnaissance sensor capability also provide value for money. Take for example the development of multi-spectral sensors for detection of camouflaged and concealed targets at longer stand-off ranges. Additionally, tactical reconnaissance sensors now have datalink connectivity resulting in an ability to pass image chips forward via airborne assets for early exploitation and analysis. Tactical reconnaissance vendors are also promoting requirements for expeditionary processing, exploitation, and dissemination (PED) cabin for deployed operations. Expeditionary PED is critical to the tactical reconnaissance mission, particularly if it is likely that communications bearers are at risk. Furthermore, the transmission of terabytes of imagery through a communications bearer for analysis may not be viable due to bandwidth constraints on protected networks.  The significant volume of imagery data collected from tactical reconnaissance pods will necessitate a form of ‘triage’ of the imagery to focus analytical efforts on priority information requirements. Therefore, sending analysts closer to the fight may be required to overcome the effects of a contested communications environment.

In a future high-intensity war, ADF will not have the unfettered use of space and Electromagnetic Spectrum (EMS) to which it has become accustomed. Near-peer adversaries such as China and Russia have made their intentions clear regarding the denial of space and communications bearers for the US and its allies during any potential conflict. Therefore, the ability to carry an imagery collection sensor on an aircraft that can penetrate and survive in contested airspace, conduct a tactical reconnaissance mission, and return the imagery for exploitation is vitally important. Early phases of a high-intensity war against a sophisticated integrated air defence system (IADS) will see our traditional ISR assets operating at significant stand-off ranges that will degrade their operational utility. The F-35 can penetrate IADS; however, the sensor suite is not optimised for long-range, wide field-of-view imagery collection. The high-end battle may require traditional reconnaissance methods to get the job done. This is particularly important for targeting intelligence and post-strike assessment – to ensure the commander apportions the right platforms and weapons against the right target sets to achieve the desired effects at the lowest risk available.

For a small but technically advanced air force like the RAAF, the acquisition of imagery sensors that can be carried in a fast jet-configured pod would provide a low-cost capability for imagery collection for use during high-intensity war, complementing available satellite and larger airborne imagery collection systems. The tactical reconnaissance pods can also be utilised in permissive environments when tasked and could be considered for use to support the full spectrum of operations. The most likely candidate platform for the ADF tactical reconnaissance capability would be the F/A-18F Super Hornet, given the already demonstrated role with the USN and SHARP. The flexibility of a podded sensor allows the fighter aircraft only to carry the pod when required vice having a permanently fixed sensor with inherent penalties of sensor carriage. An airborne tactical reconnaissance capability could provide responsive, survivable, and high-quality imagery to the joint force a range of scenarios.

Imagery collection capabilities are facing increasingly sophisticated threats across the air, electromagnetic, space and cyber domains. The development of an ADF airborne tactical reconnaissance capability would add another layer to Australia’s tactical imagery collection requirements while also enhances its self-reliant military capability and its value as a contributor to coalition ISR operations. Tactical reconnaissance provides necessary redundancy, survivability, and responsiveness required when the high-intensity war means commanders cannot access strategic collection capabilities – due to access or priorities – and reduces the information gush to a trickle. In high-intensity war and pulling the digital ‘wet-film’ imagery from a pod-equipped fighter jet may be the only viable reconnaissance method available to reveal adversary posture and intent.

Squadron Leader Rodney ‘Neville’ Barton is an officer in the Royal Australian Air Force. The opinions expressed are his alone and do not reflect those of the Royal Australian Air Force, the Australian Defence Force, or the Australian Government.

Header Image: An RAF Tornado GR4 from RAF Marham in Norfolk with a RAPTOR airborne reconnaissance pod fitted beneath the fuselage, c. 2009. The images received by the pod can be transmitted via a real-time data-link system to image analysts at a ground station or can be displayed in the cockpit during flight. The imagery can also be recorded for post-flight analysis. The RAPTOR system can create images of hundreds of separate targets in one sortie; it is capable of autonomous operation against preplanned targets, or it can be re-tasked manually for targets of opportunity or to select a different route to the target. The stand-off range of the sensors allows the aircraft to remain outside heavily-defended areas, to minimise the aircraft’s exposure to enemy air-defence systems. (Source: UK Ministry of Defence)

#highintensitywar and Alliances

#highintensitywar and Alliances

By Dr Alan Stephens

Editorial Note: Between February and April 2018, The Central Blue and From Balloons to Drones, will be publishing a series of articles that examine the requirements of high-intensity warfare in the 21st Century. These articles provide the intellectual underpinnings to a seminar on high-intensity warfare held on 22 March by the Williams Foundation in Canberra, Australia. In this article, Dr Alan Stephens considers the importance of alliances in supporting smaller powers involved in high-intensity conflicts.

It was the 19th century British Prime Minister, Lord Palmerston who famously remarked that in international relations there are ‘no eternal allies […] only interests.’

Palmerston’s hard-headed worldview has particular relevance for small- and medium-nations that find themselves drawn into high-intensity warfare. The October 1973 war in the Middle East and the 1982 war in the Falklands illustrate the point.

The 1973 war began on 6 October when Egypt and Syria launched a sudden attack against Israel. Over-confident Israeli commanders were shocked when their previously dominant air force found itself unprepared for the quality and tactical disposition of the Arabs’ ground-based air defence system. The Israeli Air Force (IAF) started the war with about 290 frontline F-4 and A-4 strike/fighters, and within days some fifty had been shot-down. It was an unsustainable loss rate.

McDonnell_Douglas_A-4F_Skyhawk_Ayit_F_(468970264)
A Douglas A-4F Skyhawk of the Israali Air Force. (Source: Wikimedia)

A week later, as the war in the air began to turn and the Israelis started to assert their expected dominance, it was the Arabs’ turn to experience unsustainable losses.

Now, both protagonists faced the same urgent problem: neither had the reserves nor the local capacity to rapidly reinforce their fighting units.

There is a limit to how much a nation can spend on otherwise non-productive war industries and stockpiles. Governments have to make fine judgments regarding how many weapons – which represent stranded assets until they are used – they can afford to have parked on ramps or stored in warehouses against the possibility of a contingency that might never arise.

That economic imperative is especially pronounced in the war in the air, in which platforms and weapons are exceedingly expensive. Moreover, in high-intensity fighting, extreme loss and usage rates accompany extreme unit costs. Thus, during the nineteen days of the October War, the Israelis lost 102 strike/fighters and the Arabs 433, and the Arabs fired 9,000 surface-to-air missiles. Those numbers alone amounted to thirty aircraft and $560 million per day.

What that meant was that neither the Israelis nor the Arabs were capable of fighting a high-intensity air war for more than about a week without direct assistance from their American and Soviet sponsors. Moreover, that is precisely what happened. On 9 October, the Soviets started a massive airlift to resupply the Egyptians and Syrians with missiles, ammunition, SAM components, radars, and much more; shortly afterwards, the US did the same for Israel. The US also made good the IAF’s aircraft losses by flying-in about 100 F-4s, A-4s and C-130s, some of which arrived still carrying United States Air Force markings.

Without that resupply, Israel and the Arab states could not have sustained such a high-intensity conflict.

This point bears emphasis. Israel was far superior militarily to the Arab states, and its excellent indigenous industry enabled it to develop essential capabilities (such as electronic warfare counter-measures) during the conflict. Nevertheless, it is not unreasonable to suggest that, had Egypt and Syria been resupplied and Israel had not, the war would have ended differently.

Sustainment in the form of aid from an external source was again crucial during the 1982 Falklands War between the United Kingdom and Argentina.

FKD 2100
A formation of Royal Navy FRS1 Sea Harriers from three of the Fleet Air Arm Squadrons that served in the Falklands War. Viewed from front to back are aircraft of No. 800 Naval Air Squadron, No. 801 Naval Air Squadron and No. 899 Naval Air Squadron. The aircraft at the front is equipped with a Sidewinder missile. (Source: © Crown copyright. IWM (FKD 2100))

The UK’s armed forces are among the world’s very best, and the nation is one of the world’s wealthiest and most powerful. Argentina in 1982 was a dysfunctional, second-world nation led by an incompetent cabal of military dictators. According to both the key foreign affairs advisor to Prime Minister Margaret Thatcher, Lord Charles Powell, and the US Assistant Secretary of Defense, Richard Perle, ‘Britain probably would have lost the war without American assistance.’ That assistance extended to providing vital intelligence, and to ‘stripping part of the frontline US air forces’ of the latest version of the Sidewinder air-to-air missile.

Argentina, by contrast, found itself the dismayed subject of Lord Palmerston’s unsentimental characterisation of alliances, when it was abandoned by two nations which, until the day the shooting started, it had believed were its friends. The first, the US, cut-off intelligence and diplomatic assistance; and the second, France, which had sold the Argentine Navy Super-Etendard strike fighters and Exocet missiles, withdrew the technical support needed to make that capability fully effective.

In the event, the Argentines managed to fire five Exocets, sinking two ships from the British war convoy and severely damaging a third. It is feasible that, with better targeting information and only a half-dozen more operational missiles, the Argentines might have inflicted sufficient damage on the convoy to have compelled it to turn back before it got within 100 kilometres of the Falklands.

Should Australia become involved in a high-intensity conflict in the next ten years, we can confidently expect that our air power would be well-trained and well-equipped. Those attributes would be insufficient in themselves, however, if they were not underwritten by a strong and reliable alliance.

N.B. This article was first published in the April 2018 issue of Australian Aviation.

Dr Alan Stephens is a Fellow of the Sir Richard Williams Foundation. He has been a senior lecturer at UNSW Canberra; a visiting fellow at ANU; a visiting fellow at UNSW Canberra; the RAAF historian; an advisor in federal parliament on foreign affairs and defence; and a pilot in the RAAF, where his experience included the command of an operational squadron and a tour in Vietnam. He has lectured internationally, and his publications have been translated into some twenty languages. He is a graduate of the University of New South Wales, the Australian National University, and the University of New England. Stephens was awarded an OAM in 2008 for his contribution to Australian military history.

Header Image: Flight deck operations on board HMS Hermes during the Falklands War, c. 1982. A Sea Harrier takes off from the ski-jump while various missiles, helicopters and vehicles crowd the flight deck of the carrier. The arms front to back include 1000lb GP bombs with type 114 ‘Slick’ tails, 1000lb GP Bombs with Type 117 parachute ‘retarded’ tails, Sidewinder air-to-air missiles and Sea Skua air-to-surface missiles. (Source: © Crown copyright. IWM (FKD 127))

Air Operations at the Level of Boots on the Ground

Air Operations at the Level of Boots on the Ground

By Sean Welsh

Editorial Note: Between February and April 2018, The Central Blue and From Balloons to Drones, will be publishing a series of articles that examine the requirements of high-intensity warfare in the 21st Century. These articles provide the intellectual underpinnings to a seminar on high-intensity warfare held on 22 March by the Williams Foundation in Canberra, Australia. In this article, Sean Walsh considers some of the issues surrounding the use of Uninhibited Aerial Vehicles with a particular focus the on the implications for ground units who may increasingly come to rely on such platforms that operate at ultra-low-levels.

Slaughterbots

In the near future air operations will happen at altitudes as low as the heel of a soldier’s boot as aircraft capable of offensive and defensive operations reduce in size and increase in range.

That this is likely is demonstrated by the slaughterbots video that went viral in November 2017. The slaughterbots are autonomous offensive drones that can fit in the palm of a human hand. Fitted with explosive warheads designed to impale human skulls, these very low altitude drones were depicted in the video as having the ability to autonomously select and engage targets based on age, sex, fitness, uniform and/or ethnicity.

The video ended with one such robot killing an unarmed student lying under a desk in a lecture theatre (a clear-cut war crime). Legitimate militaries have no interest in perpetrating genocide, but the prospect of autonomous drones attacking human combatants with explosives and projectiles is very real.

Very Low Altitude Drones

Future weaponised micro-aircraft will be capable of operations at very low altitudes – just millimetres above the ground. Indeed, some aircraft may become hoppers having the ability to fly through the air and drive on the ground.

This descent to ankle altitude of air power will fundamentally change the nature of army operations. Increasingly, they will come to resemble air force operations. Effective air power is now small enough to fit in a backpack or armoured personnel carrier. This low-altitude air power is mostly used for reconnaissance enabling an infantry unit to have an eye in the sky; however, these systems are starting to become weaponised.

In future high-intensity war, infantry units will need to be familiar with air force logistics and tactics. Future ground troops may need to be airmen as well as soldiers in that they will need to understand low altitude air war in addition to land war. Alternatively, combat airmen may need to be embedded in infantry units. One might argue this is the continuation of a process that started when the cavalry switched to helicopters from horses. Regardless of the institutional arrangements, ground units will need defensive drones, portable anti-aircraft weapons they can carry themselves, or both.

Tiers of Air Superiority

In the near future, it may be there are tiers of air superiority. At low altitudes, the air will be dominated by large numbers of relatively small and cheap aircraft flying at low speed and having relatively low range. At higher altitudes, existing air force concepts of air superiority will continue to apply. There will still relatively small numbers of expensive supersonic fighters clearing the skies of enemy aircraft but F-35s burning through the sky at high speed will be of limited use against swarms of slaughterbots flying less than 10 feet above the ground at relatively low-speed attacking infantry and other ground-based targets.

Indeed, already we have seen how such cheap low altitude drones can be used to attack expensive hi-tech aircraft sitting on the ground. In Syria, in January 2018, a low-tech attack by Syrian rebels was made on hi-tech Russia on its airbase at Hemimim and its naval station at Tartus. Militaries will find it irresistible to develop weapons costing a few hundred dollars that could destroy supersonic aircraft worth tens of millions on the ground. Naturally, countermeasures to guard against such threats have already been developed. The Russians were able to see off the attack.

As an aside, this gives the lie to the claim made in the slaughterbots video that ‘humans will have no defence’ against such attacks. In the history of war, the measure has always led to the development of counter-measures. The spear led to the shield. The submarine led to the depth charge. Barbed wire and machine guns led to tanks. The slaughterbot will lead to counter-measures just like every other technological innovation in military history.

Traditional High-Altitude Air War Will Still Be Critical

Even given the new low-altitude threats, F-35s and other fighter aircraft will still be able to target the transport planes and vans delivering the low altitude ‘slaughterbots’ to a range close enough for them to attack in a conventional war. Destruction of enemy logistics will still be a key to victory as it was in the Battle of Midway and many other historic engagements. However, given suitable terrain, it is conceivable that one belligerent in a future high-intensity war might have air superiority at altitude while the other has air superiority close to the ground.

Increasing Autonomy

Even in an asymmetric war, a plucky low-tech belligerent might find a way through the emerging countermeasures and achieve low-altitude air superiority with devastating effect to a high-tech foe. We can expect those who perpetrated the failed attack on the Russians in Syria to go back to the drawing board and try again, this time targeting the low altitude air defence systems first (perhaps with a suicidal or stealthy ground attack) before unleashing the drones on the high-value targets in the hangers.

Increasingly these low altitude aircraft will be autonomous in their combat functions. This is because such craft is far too small for an onboard human pilot. Also, in the near future, a fight between a human-telepiloted Uninhabited Air Vehicles (UAV) and an autonomous UAV will be as fair a fight as Kasparov vs Deep Blue or Sedol vs AlphaGo. There will come a time where the AI has advanced to a point where humans cannot defeat it. A further reason is that existing drone counter-measures use techniques such as jamming GPS and telepiloting frequencies. To counter the counter-measures, drone-makers could resort to dead-reckoning or visual navigation to avoid the GPS vulnerability. To avoid the telepiloting vulnerability, they could disconnect the network card and develop onboard autonomy.

U.S. Marines with 3rd Battalion, 4th Marines and Afghan National Security Forces conduct a joint checkpoint
US Marine Corps Corporal Andrew Margis of the 3rd Battalion, 4th Marines, Regimental Combat Team 7 prepares a micro unmanned aerial vehicle for flight at a joint vehicle checkpoint with Afghan soldiers and Afghan civil order police in the Now Zad district of Afghanistan’s Helmand province, 21 May 2013. (Source: US Department of Defense)

Moral Arguments regarding Lethal Autonomy

There is, of course, a moral argument here in addition to the technical ones regarding lethal offensive autonomy. It is foreseeable that there will be a ban on autonomous weapons but terrorist and criminal groups (narcoterrorists) will readily adopt such low altitude air power because of its low cost and easy availability. Indeed, they already have. ISIS weaponised telepiloted hobby drones in 2016. Drones are now being used to smuggle drugs across borders. It is only a matter of time before cartels use them to assassinate police, judges, and ministers. This will force democratic nations to adopt counter-measures. To be effective, such counter-measures, like existing close-in weapons systems such as Phalanx, will need a high degree of targeting autonomy. Historically, military necessity has trumped moral objections to many new weapons because belligerents will do whatever it takes to win.

Jefferson Davis objected to ‘torpedoes’ (mines) as ‘cowardly’ weapons, but when the Confederacy got desperate, he acquiesced to their use. Submarines and bombers were similarly objected to on moral grounds yet because they were militarily effective and could be used in compliance with principles of discrimination and proportionality, they survived. Military norms changed to accommodate them. The Campaign to Stop Killer Robots may get a ban on autonomous weapons, but these efforts may not bear fruit.

Already, the Russian military has prototyped an autonomous tank, the Neretha, which was reported to have outperformed human tank crews in recent trials. A US team of researchers have already built an air combat AI that defeated a retired Air Force colonel in a tactical simulation.

Autonomous Swarms

It is likely autonomous low altitude aircraft will function in swarms and be teamed with humans who will increasingly focus on defining military goals at a high level rather than figuring out how to achieve them in detail.

A human officer might say to a swarm of robots, ‘clear that house’ and the robots will autonomously work together to search for threats and clear it. Swarm robotics is a rapidly progressing area of research. If the swarm of robots needs to shoot enemy combatants therein (be they human or robotic) they will do so within the scope the human order “clear that house” gives them.

Similarly, having disposed of the low altitude air defence, a commander could say to his swarm ‘search for and destroy all Sukhois on this airfield’, and the robots would do this. If they needed to shoot airmen trying to defend their craft, they would do so within the scope of their human order and the normative constraints of targeting law.

At present, such human-robot teaming is not practical, but it is a defined research goal. Most drones remain telepiloted; however, voice-controlled robots that are intelligent enough to respond to simple tactical instructions are not far away, and autonomous robots intelligent enough to comply with targeting law are not so far away either.

Such airborne robots would integrate with ground-based robots. Ground-based robots will be primarily logistical with strike ability mostly airborne except for some very particular tasks, such as sneaking up like snakes on enemy low altitude air defence posts. Command and control will be distributed and redundant. Cybersecurity will be critical.

Much research and development will be needed to ensure these drones operate in accordance with targeting law. However, such research is being funded. In the absence of a policy prohibition, the advanced powers will succeed in developing normatively compliant autonomous weaponry. In a climate where major powers do not trust each other, each will keep their guard up.

Increasingly, given the advances in AI and robotics, the front line of combat will be a combination of Uninhabited Ground Vehicles and UAVs on land and Uninhabited Sea Vehicles, Uninhabited Underwater Vehicles and UAVs at sea.

Future War May Be Predominantly Robotic in the Front Line

Future war may well evolve into robot vs robot at the front line. Human resistance against robots may become futile. Should such conditions evolve in war, it may be conventions evolve to take human surrenders in such hopeless circumstances.

Indeed, future war might become as ‘civilized’ as the wars of the Italian condottieri in the Renaissance. Machiavelli wrote of the Battle of Zagonara in 1424 that it was a ‘great defeat, famous throughout all Italy’ and yet ‘no death occurred except those of Lodovico degli Obizi and two of his men, who having fallen from their horses were drowned in the mud.’[1]

Historians doubt the body count in Machiavelli’s report as he had it in for the lack of warfighting prowess of the condottieri, but even so, just as the wars of the condottieri were more about manoeuvre and posture than actual hard fighting, future war might become a matter of destroying material rather than people.

Some would argue war has been as much as about destroying material rather than people since the Second World War as evidenced by the raids on Schweinfurt and Bologna and the U-Boat campaigns in the North Atlantic. Once the opposing robots are destroyed, the humans may surrender as the ability of humans to defeat robots in combat might no longer exist. Resistance without robots may turn out to be as futile as trying to beat Deep Blue at chess without a computer.

In a future high-intensity war, it might be written:

[u]sing a new technological invention, the Red robots wiped out the Blue robots in the first days of the war, compelling the Blue humans to surrender. Some Blue humans tried to fight on, but the Red robots disarmed them, laughing at their slowness. The videos taken by the Red robots went viral.

Sean Welsh (@sean_welsh77) is the author of Ethics and Security Automata: Policy and Technical Challenges of the Robotic Use of Force and a postgraduate student in Philosophy at the University of Canterbury. Prior to embarking on his PhD, he wrote software for British Telecom, Telstra Australia, Fitch Ratings, James Cook University and Lumata.

Header Image: Pictured is a Royal Marine controlling a Black Hornet 2 Remotely Piloted Aircraft System (RPAS). This pocket sized and hand launched RPAS uses micro thermal cameras, visible spectrum cameras and proprietary software for flight control, stabilization, and communications. Weighing 18 grams, the Black Hornet helicopter can fly for up to 25 minutes at line-of-sight distances of up to one mile at speeds of 18 km/h. It uses GPS navigation or visual navigation via video and can fly pre-planned routes via its autopilot. The Black Hornet was developed in 2007 and been used by NATO forces in Afghanistan from 2011, with the United Kingdom the first to acquire the type and use it operationally. (Source: MoD Defence Imagery)

[1] Niccolo Macchiavelli, History of Florence, Book IV, Chapter I.

Society and #highintensitywar

Society and #highintensitywar

By the Reverend Dr (Wing Commander) David Richardson

Editorial Note: Between February and April 2018, The Central Blue and From Balloons to Drones, will be publishing a series of articles that examine the requirements of high-intensity warfare in the 21st Century. These articles provide the intellectual underpinnings to a seminar on high-intensity warfare held on 22 March by the Williams Foundation in Canberra, Australia. In this article, the Reverend Dr (Wing Commander) David Richardson discusses the relationship between society, political culture, and military sacrifice.

In his thoughtful account of the closing days of the Second World War, Max Hastings argues that the character of the conflict in western Europe was determined by the character of the western democracies themselves. The armies of Britain, America and their associates, he suggests, may have lacked the ruthless military prowess and determination of the German and Soviet forces, but ‘fought as bravely and well as any democracy could ask, if the values of civilisation were to be retained in their ranks’[1]. When Churchill and Roosevelt invoked ‘Christian Civilization’ as the grand cause worthy of sacrifice, they were not so much making a religious statement as appealing to a shared sense of identity which they expected their listeners to understand and relate to.  Seventy-five years later, it is by no means evident that this shared identity still holds. In this series articles published by From Balloons to Drones and The Central Blue considering the possibility of high-intensity war in the future, it is worth pausing to reflect on this relationship between political culture and military sacrifice, and some of its implications.

A 14063
Prime Minister Winston Churchill and President Franklin Roosevelt at the Casablanca Conference, c. January 1943. (Source: © IWM (A 14063))

As peace returned to the shattered remains of Europe in 1945, some positive developments followed in its wake. West of the Oder, at least, liberal democracy seemed to strike deeper roots than ever before, going hand in hand with a prosperity that followed a solid upward trajectory. Across the Atlantic, America abandoned isolationism and committed itself to be both the guardian and bankroller of freedom. The only primary rival in town, Marxist-Leninism, was seen off the stage after 1990 – it seemed as if the liberal democratic steamroller would flatten a global path for economic and personal freedom. However, all was not quite as it seemed.

Before considering just how the course of history unravelled after the fall of the Berlin Wall, it is useful to lay out – with a very broad brush – some of the presuppositions that had driven western society up to this point. From the Fall of Rome until the Enlightenment, religious horizons essentially bounded the world, symbolised most powerfully by the Holy Roman Emperor kneeling in the snow at Canossa. Architecture, art, and music all reflected this human concern about relating to the divine. Come the Enlightenment; the focus changed to working out what kind of world humans could create for themselves, relying on their unfettered reason and empirical discoveries. This was the age of science and developing democracy, which held out a dream of unending human progress. The waves of devastation which swept across Europe twice in the first half of the twentieth century cruelly mocked any such hopes. The last spasms of Enlightenment optimism at least gave birth to the liberal democratic project which seemed to triumph – and had been worth making sacrifices for.

However, the liberal democratic project rested on increasingly shaky foundations. Premodern people could find their certainties in religious truth. Enthusiasts for the Enlightenment could base their philosophy on a confidence that the truth was out there for any rational person to discover. Although these two views were divergent in almost every respect, they had this in common – a belief in a transcendent universe which provided a framework for understanding the place of human beings in the world.[2] As James Davison Hunter expresses it, there was a ‘common grammar for recognising the natural affections and moral sentiments shared by all humanity…the seeds of social solidarity could be found in human sentiments, the public good within private interests, the universal within the individual’[3]. This is precisely the transcendent worldview assumed by Churchill and Roosevelt in 1945. One of the tragic ironies of recent history is that, just as the liberal democratic project appeared to triumph, its internal coherence began to dissolve.

To put it crudely, liberal democracy bifurcated into liberal and democratic elements. Regarding liberalism, this was not the classic liberalism that Adam Smith would have recognised. Instead, it is something new – neoliberalism. The underlying assumption behind this concept is that the market is sovereign – and not merely over economic issues. Based on the theory of Friedrich Hayek, nothing has a given and immutable value – even those aspects of human significance and meaning that previous generations would have treated as normative. Objective truth is no longer ‘out there’ to be revealed or reasoned out but is determined by what the market will bear. As Stephen Metcalf points out, the old political processes of public reason – debate and thoughtful argument –  are incongruent with this process, as in market terms they are simply opinions. What happens instead is that the public square ‘ceases to be a space for deliberation, and becomes a market in clicks, likes and retweets’[4]. There is no longer a shared, transcendent mise en scène for human existence. Virtues have transformed into values – individually held and formulated – but of no binding or enduring significance.

Regarding democracy, the individual now has an unprecedented status. Once seen in relation to divinity or wider society, human beings are now increasingly regarded as sovereign agents. As the public sphere has become eviscerated of a shared cultural story, the individual is now free to decide his or her path through life.  Alternatively, so the theory goes. Jackson Lears expresses it like this – ‘redefined as human capital, each person becomes a little firm with assets, debts, and a credit score anxiously scrutinised for signs of success or failure’[5]. The individual may be freer to choose than ever before, but also carries an increasingly heavy burden for their destiny. Lacking the safeguards of a benevolent Providence – or a paternalistic society – the individual must shift for themselves. The mantra that every schoolchild knows so well – ‘follow your dreams and you can achieve whatever you want’ has a darker side that few if any primary school assemblies ever spell out. Failure to achieve those dreams or ambitions will be your responsibility alone. In such a culture, the individual faces an unrelenting pressure to boost their own image and status above all else. For example, an intriguing textual analysis of Norway’s main national newspaper between 1984 and 2005 revealed that as the occurrence of self-referencing words such as ‘I’ and ‘my’ increased, instances of other-focused concepts such as ‘duty’ and ‘obligation’ declined[6].

What, if anything, does all this have to do with high-intensity warfare in the twenty-first century? Going back to where we began, the armies which liberated western Europe in 1945 did so against a broadly shared cultural outlook. Britannia, Marianne, and Columbia are hardly identical sisters, but bequeathed a remarkably similar legacy of shared understanding to their descendants – and the freedoms for which they gave their lives had a transcendent quality. This situation, it may be argued, no longer obtains. Evidence for this can be seen in a wide variety of forms, from Allan Bloom’s analysis of education to Robert Putnam’s influential work on the decline of social cohesion in late twentieth century America[7].  As the Canadian philosopher Charles Taylor observes, ‘the individual has been taken out of a rich community life and now enters instead into a series of mobile, changing, revocable associations’[8]. With his or her small stock of human capital, each person makes their way through life via a series of short-term contracts, which run the gamut of human existence from car insurance to employment. What matters most is the utilitarian and the instrumental – an epistemic ecology where traditional concepts such as humility, duty and sacrifice seem anachronistic surds. Moreover, as analysts of our neoliberal world have suggested, the promised blessings of prosperity and success have not trickled down universally, leading to a considerable degree of cynicism about public life – from fake news to the political establishment. This is not a development which augurs well for a strong common existence. If citizens withdraw from political and civic engagement into a private sphere of personal fulfilment, as Larry Siedentop remarks, liberal freedoms are at risk[9].

PUMA SQUADRON MARKS 100 YEARS
An RAF Puma deploying flares whilst on Operation TORAL in Afghanistan, c. 2016. (Source: MoD Defence Imagery)

One of the founding principles of modern democracy is that the individual citizen surrenders certain freedoms and benefits to the state in exchange for protection and stability. This relationship is perhaps seen in its starkest form when a nation sends its citizens to war. In the post-2001 operations, when the legitimacy of the campaigns was subject to intense public scrutiny, this affected the commemoration of those citizens who had given their lives. As Sandra Walklate, K.N. Jenkings and others have observed, repatriation ceremonies became ‘deeply political acts’ protesting against military action, where those who died were remembered as victims of government policy[10]. Anthony King, in his analysis of the obituaries of British service personnel, comments that the death of soldiers is not seen so much as an act of service for the nation as ‘the meaningful expression of a man who defined himself by his profession’[11]. If the individual is indeed a small firm with a limited stock of human capital, a strong relationship of trust between citizen and society is vital should the citizen be required to sacrifice that capital for a bigger purpose.

Moreover, this is the nub of the argument. As Alexis de Tocqueville saw some two centuries ago, a society which favours atomism and instrumentalism undermines the very freedoms which it cherishes.[12] Since the fall of the Berlin Wall, the freedoms that the western world enjoys have primarily been sustained without significant periods of high-intensity conflict – and the associated heavy demands of blood and treasure. Future military operations may not follow this pattern, and free nations may have to pay a large price for such nebulous terms as liberty and democracy. A worldview furnished from the moral stockroom of utilitarian instrumentalism will offer little strength in such circumstances. To quote Taylor again, ‘high standards need strong sources’ – a stripped down public square does not provide the wherewithal to sustain a deep understanding of human meaning and purpose.[13] Churchill and Roosevelt saw the battle that they were engaged in as something more than a struggle over resources and the possession of territory.

Alternatively, in other words, they understood the need for spiritual resilience – an awareness that human existence cannot be reduced to a profit and loss transaction. The free society which values the individual did not arise from an instrumentalist worldview – indeed Siedentop has recently published a fascinating volume which explicitly traces the development of modern liberal equality right back to Christian thinkers in the middle ages.[14] One does not need to share the faith of these scholars to appreciate their insights. Perhaps it is time to pause in our pursuit of relentless individualism to consider the bigger truths of the world to which we belong. Davison Hunter remarks that our current cultural trajectory is likely set to bend us away from the very concepts of justice, freedom, and tolerance that we treasure. Before we are called upon to defend these convictions in intensive conflict, it is undoubtedly worth reflecting on why they are worth defending in the first place.

The Reverend Dr (Wing Commander) David Richardson is a chaplain in the Royal Air Force, initially ordained into the Church of Ireland. A graduate of the universities of Edinburgh, Dublin, Belfast, and King’s College London, he has served on a variety of RAF stations. His operational experience includes tours across Afghanistan and Iraq.

Header Image: Stretcher bearers of the Red Crescent evacuate a civilian casualty in Basra during Operation TELIC. (Source: © Crown copyright. IWM (OP-TELIC 03-010-37-091))

[1] Max Hastings, Armageddon: The Battle for Germany, 1944-45 (London: Macmillan, 2004) p. 588.

[2] James Davison Hunter, ‘Liberal Democracy and the Unravelling of the Enlightenment Project,’ The Hedgehog Review, 19:3 (2017).

[3] Ibid.

[4] Stephen Metcalf, ‘Neoliberalism – the idea that swallowed the world,’ The Guardian, 18 August 2017.

[5] Jackson Lears, ‘The long con of Neoliberalism,’ The Hedgehog Review, 19:3 (2017).

[6] Jean Twenge and Keith Campbell, The Narcissism Epidemic (New York, NY: Free Press, 2010), p. 264.

[7] Allan Bloom, The Closing of the American Mind (London: Penguin, 1987); Robert Putnam, Bowling Alone (New York, NY: Touchstone, 2000).

[8] Charles Taylor, Sources of the Self (Cambridge: Cambridge University Press, 1992), p. 502.

[9] Larry Siedentop, Inventing the Individual (London: Penguin, 2014), p. 363.

[10] Sandra Walklate, Gabe Mythen and Ross McGarry, ‘Witnessing Wootton Bassett; An Exploration in Cultural Victimology,’ Crime, Media and Culture, 7:2 (2011), pp. 149-65. K.N. Jenkings, N. Megoran, R. Woodward and D. Bos, ‘Wootton Bassett and the political spaces of remembrance and mourning,’ Area, 44:3 (2012), pp. 356-63.

[11] Anthony King, ‘The Afghan War and ‘postmodern’ memory: commemoration and the dead of Helmand’, The British Journal of Sociology, 61:1 (2010), pp. 1-25.

[12] Quoted in Taylor, Sources of the Self, p. 502.

[13] Ibid., p. 516.

[14] Siedentop, Inventing the Individual.
